Plate 188-2
Deck plan and side and interior plan of the whaling schooner Amelia, of New Bedford, Mass.
[Click on image to view in higher resolution.]

THE WHALE FISHERY.
Side and interior plan of the
whaling schooner Amelia, of New Bedford, Mass.
95.44 tons.

(Sect. v, vol. ii, p. 234.)
Drawing hy C. S. Raleigh.


[Go to an expanded view of this image with labels.]

Fig. 2. Side and interior plan. –

1, Bowsprit. 18, Mainmast.
2, Paul-bitt. 19, After hatch.
3, Windlass and bitts. 20, Galley.
4, Forecastle companion. 21, Cabin skylight.
5, Foremast. 22, Cabin companion.
6, Forecastle. 23, Side whale boat.
7, Chain cable box. 24, Steering screw box.
8, Try-pots. 25, Stern whale boat.
9, Try-works. 26, Spare spars, oars, &c.
10, Chimney and flue. 27, Boat davits.
11, Main hatch. 28, Boat bearers.
12, Locker for coal. 29, Main hold.
13, Casks for oil. 30, Cat-head.
14, Ship stores, gear, &c. 31, Cutting blocks, gear, &c.
15, Captain's store-room. 32, Pumps.
16, Captain's cabin. 33, Main channels.
17, Steerage. 34, Fore channels.

Source.
George Brown Goode.
      The fisheries and fishery industries of the United States.
Section V, History and Methods of the Fisheries ... Plates.
1887.
At head of title page: "United States Commission of Fish and Fisheries, Spencer F. Baird, Commissioner."
Also on title page: "Prepared through the cooperation of the Commissioner of Fisheries and the Superintendent of the Tenth Census by George Brown Goode, Assistant Secretary of the Smithsonian Institution and a staff of associates."
Also published as: Serial Set Vol. No. 2003, (47th Congress, 1st Session. Vol. No. 11, Misc.Doc. 124, pt. 7.)
288 p.
Maps Illustrations.

This publication may be found at HathiTrust.
